How To Install LED DRL Boards On Your BMW 5 Series G30 LCI

At DrlsDirect, we are dedicated to providing detailed guides and valuable information to automotive enthusiasts like you. In this comprehensive guide, we will walk you through the process of installing new DRL LED boards on your BMW 5 Series G30 LCI. This installation will not only transform the appearance of your car but also give it a unique and eye-catching look. If you're interested in purchasing new DRL boards for your 5 Series G30 LCI, be sure to check out our shop.

Note: If you are not comfortable with vehicle electrical systems or the installation process, consider seeking professional assistance to ensure the modification is performed safely and correctly. Our DRL LED boards are designed to fit only original headlights and are not suitable for aftermarket headlights.

Installation Process

Before we dive into the installation process, it's important to ensure the ignition is off and the battery is disconnected, to prevent electrical issues.

Step 1: Preparation and Removal of Front Bumper
  1. Lift the car using a lift or jack to create enough space to work comfortably.
  2. Remove the plastic pieces and items surrounding the front section of the car.
  3. Carefully detach the grills and other necessary components.
  4. Take off the wheels to gain access to the fender liner.
  5. Remove the screws holding the fender liner in place.
  6. Disconnect any connectors and carefully pull out the fender liner. Repeat the process on the opposite side of the car.
  7. Remove the plastic fasteners and bolts holding the front bumper.
  8. Gradually detach the front bumper by tugging and pulling it from both sides. Take your time to ensure a smooth removal process.
Step 1 Image
Step 2: Headlight Removal
  1. Remove the screws holding the headlight in place.
  2. Disconnect any connectors and carefully pull out the headlight.
Step 2 Image
Step 3: Accessing and Installing the LED DRL Boards
  1. Locate the DRL module on the backside of your headlights.
  2. Remove the module by unscrewing 3 torx screws.
  3. When removing the module, be careful as it has a connector that needs to be unplugged.
  4. Carefully remove the existing DRL boards from the module.
  5. Install the new DRL boards in the same position and secure them in place.
  6. Ensure that the connections are secure and the boards are properly seated.
  7. Reinstall the module to your headlight.
Step 3 Image
Step 4: Installing The Bluetooth controller
  1. This step is only for the RGB+W variant! To properly control the light of the DRL boards, it is necessary to install the Bluetooth controller. Follow the included instructions and place the controller in the engine compartment, using either double-sided adhesive or zip ties to secure it to the underside of the core support.
Step 4 Image
Step 5: Testing
  1. Before we continue with the installation, please check the function. Connect your headlight as a test (take a soft cloth and place the headlight on the front of the vehicle to connect the plugs or place the headlight directly in the original position without fixing it), also connect the battery and test for function.
  2. The same applies to the RGB variant, except that the app called "Colorful Lights" must also be downloaded (available for IOS and Android). Open the app and connect to the Bluetooth module. Now test different colors, brightness levels, and modes.
Step 5 Image
Step 6: Reassembling the Car
  1. With the new DRL LED boards installed, it's time to put everything back together. Reinstall everything in reverse and take your time for a clean result.
Step 6 Image


We hope this guide has been helpful to you, and we encourage you to consult professionals or experienced individuals if you have any doubts or concerns during the installation process. Remember, your safety is paramount, so always disconnect the battery before working with electrical components.

Thank you for choosing DrlsDirect as your trusted source for automotive lighting and information. Safe driving!
