We at DRLsDirect.com are thrilled that you've chosen our DRL (Daytime Running Light) LED Chip to augment the aesthetics of your esteemed Mercedes-Benz A-Class (W176), C-Class (W205), CLA (C117), or CLA Shooting Brake. These LED DRL boards will transform your vehicle's daytime running lights, elevating its overall appeal. This article serves a general guide to aid you through the installation process of your DRL LED Chip (single color) and also the installation of the RGB version.



Note: While we currently don't offer a model-specific guide, this general guide should assist you through the installation process. If the installation process seems complex, we recommend enlisting the help of a professional or maybe do a research on YouTube.



Tools You'll Need

  • A compatible screwdriver set
  • A clean cloth or microfiber towel
  • Safety gloves (optional but recommended)



Installation Procedure



Preparing Your Vehicle:

  1. Position your vehicle on a level surface with the engine switched off.
  2. Turn the steering wheel to one side for easy access to the wheel well cover plate.



Accessing the Headlight Module:

  1. Locate and unscrew the wheel well cover plate using a suitable screwdriver. Keep these components for later use.
  2. You should now have access to the headlight module.



Removing the Heat Sink Module:

  1. Detach any connectors or wiring harnesses from the headlight module.
  2. Carefully remove the module from its position.



Removing the Original DRL Boards:

  1. Dissemble the original DRL board from the heat sink module.
  2. Utilize the required tools to unfasten the original DRL board.
  3. Disconnect any associated connectors or wiring.
  4. Note the positioning and orientation of the original Light PCB for future reference.



Installing the New DRL LED boards:

  1. Position the new DRL LED board in the original mounting points on the heat sink module.
  2. Connect the chip and secure it using the provided screws, clips, or connectors, following the manufacturer's guidelines.



Reconnecting the Heat Sink Module:

  1. Recheck all connections to verify the secure installation of the LED board.
  2. Reconnect the heat sink module to its original location.
  3. Reattach any wiring harnesses or connectors that were disconnected.



Reinstalling the Cover Plate:

  1. Align the cover plate with the mounting holes and reposition it back into the wheel well.
  2. Reinsert and secure the screws or fasteners.
  3. Ensure the cover plate is flush with the wheel well and sealed properly.



Conducting Final Checks:

  1. Inspect the installation area for any loose parts or wiring before starting the vehicle.
  2. Clean the headlight lens and surrounding areas to remove any residues.



Testing and Verifying:

  1. Activate the daytime running lights after starting your vehicle.
  2. Verify the newly installed DRL LED Chip's functionality.
  3. Confirm the lights illuminate as expected and the color change feature operates correctly.
  4. Conduct a brief test drive to ensure proper functioning of the lights in motion.



Installation of RGB DRL Boards

If you're installing RGB boards, the process remains largely the same as described above. However, additional steps are required due to the color-changing feature inherent to RGB boards.



Board Installation:

  1. Install the RGB boards following the same steps outlined in the general installation guide above.



Power Connection:

  1. After installing the RGB boards, connect the harness and Bluetooth module to a switched power source located in the engine bay fuse box.



Setting Up the Controller:

  1. Once the power connection is established, extend the wiring harness from the boards to the RGB controller. This controller is the hub for controlling the RGB feature.



App Setup:

  1. A QR code is provided on the back of the RGB controller. Scan this QR code to download the corresponding app for controlling the RGB lights.



By adhering to these steps, you'll be equipped to successfully install and enjoy the features of your new RGB boards. Handle all components with care to ensure the best results and longevity of your new LED lights.



Conclusion

On successful completion of the steps outlined above, your vehicle will sport a noticeable aesthetic boost, courtesy of the DRL LED Chip from DRLsDirect.com. Should you encounter any difficulties or require further clarification, please do not hesitate to seek professional help, refer to your vehicle's manual, or conduct additional research, such as viewing related YouTube videos.
